Brooks 9600 - Compressor Weight; Electrical Input Specifications

©2013 Brooks Automation Inc. Pub. No. 8040444, Rev. AA, 01/14/2013 ECO No. 63723 1-5
9600 Compressor Installation, Operation and Maintenance Instructions
Weight
The weight of the Compressor is listed in Table 1-1.
Electrical
The electrical specifications of the Compressor are listed in Table 1-2.
Table 1-1: Compressor Weight
Weight lbs./kg
250/114kg
Table 1-2: Electrical Input Specifications
Parameter Value
Operating Voltage Range 180 - 253 VAC
Line Frequency 50/60 Hz
Phase 3
Nominal Input Power 5.5 KW
Nominal Power Factor 0.85
Rated FL/LR* Current 16.2/80
Minimum Electrical Service 30 Amps
*FL/LR = Full Load/Locked Rotor
