Brooks 9600 - Schematic Diagrams; Introduction to Schematics; Basic Control Assembly Legend

©2013 Brooks Automation Inc. Pub. No. 8040444, Rev. AA, 01/14/2013 ECO No. 63723 D-1
Document Title
Appendix D - Schematic
Introduction
The schematic in Appendix C supports the 9600 (Low Voltage)
Compressor BROOKS-CRYOGENICS P/N 8135164P001.
Table D-2: Basic Control Assembly Legend
Identifier Description
1M Compressor Motor
J15 Module Power Receptacle
J1/P1 Autoset Power Connector
J2/P2 Unload Solenoid Connector
J3/P3 Oil Solenoid Connector
J4/P4
J5/P5
J6/P6 Compressor Contactor Coil
J7/P7 Output Connector
CB1 Main Circuit Breaker (25A)
CB2 Control Circuits Circuit Breaker (7A)
ETM1 Elapsed Time Meter
M1 Contactor 7.5 HP IEC
M1OL Relay, Overload (16-24A)
PM1 Phase Monitor OMRON RDR-TFY-M
PWB1 PWB Autoset
T4 Transformer Assembly Control
LT1 Lamp, 24-28V LED Green
J8/P8 ETM1 Connector
J9/P9 LT1 Connector
J10/P10 T3 Input Connector
