Brooks GF Series Supplemental Manual

Installation and Operation Manual
X-DPT-EtherCAT-GF1XX-MFC-eng
Part Number: 541B219AAG
April, 2017
23
Section 3 - Slave Configuration
Brooks EtherCAT MFCs
3.4.1. Manufacturer Specific Inputs
Table 3-9 – Manufacturer Specific Inputs
Index
Sub
Index
Data
Type
Access
Name
Description
Device Profile(s)
Supported
0x2000
USINT
R
Sensor: Flow Totalizer
All
0x01
ULINT
RW
TxPDO
Flow Total
All
3.4.2. Manufacturer Specific Configuration Data
Table 3-10 – Manufacturer Specific Configuration Data
Index
Sub
Index
Data
Type
Access
Name
Description
Device Profile(s)
Supported
0x4000
Sensor Flow
All
0x01
Real
RW
Alarm Threshold
High
Specified in Flow Units
(0x8000:01)
All
0x02
Real
RW
Alarm Threshold
Low
Specified in Flow Units
(0x8000:01)
All
0x03
Real
RW
Alarm Settling
Time
milliseconds
All
0x4001
Sensor Pressure
EMFC, EMFM
0x01
Real
RW
Alarm Threshold
High
Specified in Pressure Units
(0x8001:01)
EMFC, EMFM
0x02
Real
RW
Alarm Threshold
Low
Specified in Pressure Units
(0x8001:01)
EMFC, EMFM
0x03
Real
RW
Alarm Settling
Time
milliseconds
EMFC, EMFM
0x4008
Sensor Flow
MFC, EMFC
0x01
Real
RW
Alarm Deviation
Error Band
Specified in Flow Units
(0x8000:01)
MFC, EMFC
0x02
Real
RW
Alarm Settling
Time
milliseconds
MFC, EMFC
0x400B
Display Masks
All
0x01
UDINT
RW
Display Mask,
Device Errors
A Bitmask to Enable/Disable
the reporting of Device Errors
on the display per Table 2-3.
All
0x02
UDINT
RW
Display Mask,
Device Warnings
A Bitmask to Enable/Disable
the reporting of Device
Warnings on the display per
Table 2-3.
All
0x03
UDINT
RW
Display Mask,
A Bitmask to Enable/Disable
All
