Brooks GF Series Supplemental Manual

Installation and Operation Manual
X-DPT-EtherCAT-GF1XX-MFC-eng
Part Number: 541B219AAG
April, 2017
30
Section 3 – Slave Information
Brooks EtherCAT MFCs
consecutive modules (for ETG.5003 =
0x10), e.g. 0x7000, 0x7010
0x02
UNIT
RO
Maximum Number of
Modules
Up to 255 modules are possible. A device
can support less than this. This entry
described the supported number of
modules
0xF010
0x01
UDINT
RO
Module Profile List
Each sub-index lists the profile-number of
the corresponding module (hexadecimal
representation, i.e. SDP 2000 is 0x07D0)
Bit 15…0: SDP Number Bit 31...16:
0x0000
3.7. Value Range Setting
3.7.1. Exception Handling Data
See Section 4 for more information on Exceptions Implementation.
Table 3-16 – Value Range Setting
Index
Sub
Index
Data
Type
Access
Name
Description
Device
Profile(s)
Supported
0xF380
USINT
RO
TxPDO
Active
Exception
Status
A condensed summary byte
describing the collection of active
device exceptions after
corresponding masks (0xF3Ax)
were applied.
Bit 0: Device Warning
Bit 1: Manufacturer Warning
Bit 2: Device Error
Bit 3: Manufacturer Error
Bit 4...7: Reserved
All
0xF381
0x01
UDINT
RO
TxPDO
Active
Device
Warning
Details
Expanded details of the SDP
specific device warning exceptions
Bit 0-3: Reserved
All
0xF382
0x01
UDINT
RO
TxPDO
Active
Manufacturer
Warning
Expanded details of the
manufacturer warning exceptions
specified by the manufacturer
All
