Brooks GF Series Supplemental Manual

Installation and Operation Manual
X-DPT-EtherCAT-GF1XX-MFC-eng
Part Number: 541B219AAG
April, 2017
24
Section 3 – Slave Information
Brooks EtherCAT MFCs
Manufacturer
Errors
the reporting of Manufacturer
Errors on the display per Table
2-3.
0x04
UDINT
RW
Display Mask,
Manufacturer
Warnings
A Bitmask to Enable/Disable
the reporting of Manufacturer
Warnings on the display per
Table 2-3.
All
3.5. SDP Device Type Specific Data
3.5.1. Input Data
Table 3-11 – Input Data
Index
Sub
Index
Data
Type
Access
Name
Description
Device Profile(s)
Supported
0x6000
Sensor: Flow
(floating)
All
0x01
REAL
RO
TxPDO
Flow Reading
Current Flow Reading
Units: Per Flow Data Unit
All
0x6001
Sensor:
Pressure
(floating)
EMFC, EMFM
0x01
REAL
RO
TxPDO
Pressure
Reading
Current Pressure Reading
Units: Per Pressure Data Unit
EMFC, EMFM
0x6002
Sensor:
Temperature
(floating)
EMFC, EMFM
0x01
REAL
RO
TxPDO
Temperature
Reading
Current Temperature Reading
Units: Per Temperature Data
Unit
EMFC, EMFM
0x6004
Sensor: Flow
(integer)
All
0x01
INT
RO
TxPDO
Flow Reading
Current Flow Reading
Units: COUNTS(-32768 to
+32767, 24576=100%FS)
All
0x6005
Sensor:
Pressure
(integer)
EMFC, EMFM
0x01
INT
RO
Pressure
Current Pressure Reading
EMFC, EMFM
