Installation and Operation Manual
X-DPT-EtherCAT-GF1XX-MFC-eng
Part Number: 541B219AAG
April, 2017
43
Section 4 - Exceptions Implementation
Brooks EtherCAT MFCs
A Bitmask to Enable/Disable the reporting of
Manufacturer Warnings per Table 4-2. A bit
defined as a 1 enables the corresponding
exception.
A Bitmask to Enable/Disable the reporting of
Manufacturer Warnings per Table 4-3. A bit
defined as a 1 enables the corresponding
exception.
Display Mask,
Device Errors
A Bitmask to Enable/Disable the reporting of
Device Errors on the display per Table 2-3.
Display Mask,
Device Warnings
A Bitmask to Enable/Disable the reporting of
Device Warnings on the display per Table 2-3.
Display Mask,
Manufacturer Errors
A Bitmask to Enable/Disable the reporting of
Manufacturer Errors on the display per Table
2-3.
Display Mask,
Manufacturer
Warnings
A Bitmask to Enable/Disable the reporting of
Manufacturer Warnings on the display per
Table 2-3.
* Manufacturer defined
The GF1XX MFC supports exceptions as defined in Table 4-2, Table 4-3, and Table 4-4. See Section 4.1 for
additional details on each condition.
Table 4-2 – Device Errors
Pressure Out of Range High
Pressure Out of Range Low
Temperature Out of Limits
High
Temperature Out of Limits
Low
Table 4-3 – Manufacturer Errors
Non-Volatile Write Failure
Network Interface Failure
Selected Calibration Invalid
Identity Information Mismatch
