Brooks GF Series Supplemental Manual

Installation and Operation Manual
X-DPT-EtherCAT-GF1XX-MFC-eng
Part Number: 541B219AAG
April, 2017
34
Section 3 – Slave Information
Brooks EtherCAT MFCs
0xF9F0
STRING(n)
RO
Manufacturer
Serial Number
A string representing the
manufacturer’s serial
number for the device.
Note: This may have the
same value as 0x1018:04.
All
0xF9F1
0x01
UDINT
RO
CDP Functional
Generation
Number
Common device profile
functional generation
number which this device
supports.
All
0xF9F2
0x01
UDINT
RO
SDP Functional
Generation
Number
SDP functional generation
number which this module
supports. It shall be
specified by each SDP.
All
0xF9F3
STRING(n)
RO
Vendor Name
String identifying the
vendor text.
All
0xF9F4
0x01
STRING(n)
RO
Semiconductor
SDP Device
Name
String identifying the
device type of this device,
as defined by the SDP.
All
0xF9F5
0x01
USINT
RW
RxPDO
TxPDO
Output Identifier
The host (e.g. PLC
application) increments this
value each output change
to verify the device has
received the output(s). The
slave shall not change the
received value. Value shall
be copied to the TxPDO if
0xF9F5 is mapped.
All
0xF9F6
UDINT
RO
Time since power
on
Time since device has
been powered on in
seconds.
All
0xF9F7
UDINT
RO
Total time
powered
Total time device has
received power in seconds.
It persists through power
cycle.
All
0xF9F8
UDINT
RO
Firmware Update
Functional
Generation
Number
FW Update Functional
Generation Number
supported by the
device/module. Value shall
be specified by the
Firmware Update Profile
(ETG.5003-2)
All
