Brother ADS-1300 - Page 259

Remove the Output Tray
1. Close the Document Stopper (1) and collapse the Output Tray (2).
2
1
2. Gently fold the Document Support Arms (1), and then close the Top Cover (2).
1
2
3. While pressing the switch on the left side down, slide the machine to the right.
1
2
4. Lift up the main unit to remove it.
Related Information
• Replace Supplies
254
