(22) Remove the CR timing belt from the head/carriage unit.
(23) Press both rear ends of the leveler roller ASSY inwards to remove the CR guide rail through the
2 notches.
(3_043)
Leveler roller ASSY
CR guide rail
Upper cover
Notches
