1.3.16 Fine Adjustment of Scanning Position (Maintenance mode 54)
<Function>
This function adjusts the scanning start and end positions of ADF.
<Operating Procedure>
(1) Press the [5] and [4] keys in this order in the initial stage of the maintenance mode.
The machine displays "SCAN ADJ SELECT" on the LCD.
(2) To adjust the right and left edges, press the [0] key. The machine displays "RL EGDE **" on
the LCD.
To adjust the top edge, press the [1] key. The machine displays "TOP EDGE **" on the LCD.
To adjust the bottom edge, press the [2] key. The machine displays "BOTM EDGE **" on the
LCD.
(3) Enter the correction value (in units of 0.1 mm) multiplied by 10.
To increase the value by 10 (1.0 mm), press the [ ] button; to decrease it, press the [ ] button.
To increase the value by 1 (0.1 mm), press the [ ] button; to decrease it, press the [ ] button.
Note • Pressing the [CLR] button resets the correction value to 0.
• Pressing the [Stop] or [X] key returns the machine to the initial stage of the maintenance
mode without making changes of the correction value.
(4) When finished making the change, press the [SET] or [OK] key.
The machine displays "Accepted" on the LCD and returns to the initial stage of the
maintenance mode.
