Brother DCP-J752DW

3-52
Confidential
(10) Remove the ADF cover ASSY.
ADF separation pad holder ASSY
(11) Remove the ADF separation pad holder and its spring.
Note Be careful not to let the spring to fly out.
Assembling Note Insert the spring first into the opening then attach the ADF separation pad holder.
(3_068)
Upper document chute
ADF cover ASSY
(3_069)
ADF separation pad holder
Spring
ADF cover ASSY
