5-73
Confidential
Selector 7: Unidirectional print (for higher print quality)
The machine prints bidirectionally by default. To get higher print quality, set this selector to "1"
to switch to the unidirectional print mode. In this mode, printing is performed only when the
head/carriage unit travels from left to right. Note that the unidirectional print mode sacrifices
the print speed.
Selector 8: Improvement of paper feeding reliability
Setting this selector to "1" improves the paper feeding reliability, sacrificing the print speed.
Print object Unidirectional print
Print FAX message received Yes
Copy Yes
Print from PC No
Print from memory cards or via PictBridge Yes
Print memory card index or PictBridge index Yes
Print a list Yes
Printout of Test Pattern No
