Brother DCP-J752DW

2-62
Confidential
■ The entire image is light
<User Check>
- Check if the recording paper used is according to specifications.
- Check whether the paper type setting is correct.
- Carry out head cleaning.
- Replace the ink cartridge.
Step Cause Solution
1 Maintenance unit stained Clean the maintenance unit.
(Refer to Section 4.3.2 in this chapter)
2 The head property value is
incorrect
Enter the head property value.
(Refer to Chapter 5, Section 1.3.25)
3 Head calibration not performed Perform head calibration.
(Refer to Chapter 5, Section 1.3.2)
4 Non-discharge of ink from head Carry out the recommended purge procedures. Refer
to "Recommended purge procedures" in Chapter 5,
Section 1.3.29 "Purge Operation (Maintenance mode
76)".
5 Carriage PCB defective Replace the carriage PCB ASSY.
6 Maintenance unit defective Replace the maintenance unit.
7 Head defective Replace the head/carriage unit.
8 Main PCB defective Replace the main PCB ASSY.
