HL-5240/5250DN/5270DN/5280DW SERVICE MANUAL
Confidential
5-69
(11) Lift up the back of the Separation pad ASSY MP to the direction of 11a and pull up the
Separation pad ASSY MP to remove.
Fig. 5-110
(12) Remove the MP separation spring from the MP frame.
Fig. 5-111
Separation pad ASSY MP
MP frame
MP frame
MP separation spring
11a
11b
