CHAPTER 5 DISASSEMBLY AND RE-ASSEMBLY
Confidential
5-80
(7) Remove the Gear 21-16.
Fig. 5-131
(8) Remove the Gear 15.
Fig. 5-132
Paper tray
Gear 21-16
Paper tray
Gear 15
