Brother MFC-J2310 Service Manual

Confidential
2-68

Light
 Dark
User Check
- Check whether the recording paper being used is within the
specification.
- Check whether the paper type setting is correct.
- Carry out head cleaning.
- Replace the ink cartridge.
Step Cause Solution
1 Maintenance unit stained Clean the maintenance unit (refer to Section 4.3.2 in
this Chapter.)
2 Wrong head property value Input the head property value (refer to Chapter 5,
Section 1.3.25.)
3 Head correction uncompleted Input the head correction data (refer to Chapter 5,
Section 1.3.2.)
4 Non-discharge of ink from head Perform the recommended purge procedures.
Refer to "Recommended purge procedures" in
Chapter 5, Section 1.3.29 "Purge Operation
(Maintenance mode 76)."
5 Carriage PCB defective Replace the carriage PCB ASSY.
6 Maintenance unit defective Replace the maintenance unit.
7 Head defective Replace the head/carriage unit.
8 Main PCB defective Replace the main PCB ASSY.
User Check
- Check whether the paper type setting is correct.
Step Cause Solution
1 Maintenance unit stained Clean the maintenance unit (refer to Section 4.3.2 in
this Chapter.)
2 Wrong head property value Input the head property value (refer to Chapter 5,
Section 1.3.25.)
3 Head correction uncompleted Input the head correction data (refer to Chapter 5,
Section 1.3.2.)
4 Carriage PCB defective Replace the carriage PCB ASSY.
5 Maintenance unit defective Replace the maintenance unit.
6 Head defective Replace the head/carriage unit.
7 Main PCB defective Replace the main PCB ASSY.
