Confidential
2-49
Error Code 8C
Excessive current protection activated for the driver IC during recording paper feed motor
operation.
User Check
- Remove the jammed paper in jam clear cover part, platen part and front part.
Error Code 8F
Paper feed motor cannot stop.
PRINTER JAM
LCD
Step Cause Solution
1 Foreign materials in the feeding
path
Remove foreign materials.
2 PF encoder sensor defective Replace the PF encoder sensor.
3 Paper feed motor defective Replace the paper feed motor.
4 Main PCB defective Replace the main PCB ASSY.
Unable to Print 8F
LCD
Step Cause Solution
1 Paper feed motor harness
connection failure
Reconnect the paper feed motor harness.
2 PF roller belt out of place Set the PF roller belt into place.
3 Main PCB defective Replace the main PCB ASSY.
To Next Page
