3-107
Confidential
9.30 Switchback Roller
(1) Remove the switchback inner paper guide.
(2) Remove the two switchback side frames.
(Rear)
(Front)
Lower cover
Switchback inner
paper guide
Switchback
side frame
Switchback
side frame
(3_091_E)
