3-62
Confidential
9.6 Upper Cover
(1) Remove the six screws (TAPTITE BIND B M4x12 (black)) and take off the upper cover.
TAPTITE BIND B M4x12 (black)
Upper cover
Lower cover
(Rear)
(Front)
(3_035_E)
