Brother MFC-J2310

3-125
Confidential
9.40 T1 Paper Pull-in Roller
For the paper pull-in roller with belt drive
(1) Release the two hooks of the paper pull-in roller holder and remove the T1 paper pull-in
rollers and their holder from the gear holder ASSY.
Hook
Hook
Paper pull-in roller holder
T1 paper pull-in roller
(3_027_1_E)
