Brother MFC-J2310

3-18
Confidential
The tubes colors may change due to circumstances.
9 Drain tube
10 Lower side cover R
Drain tube (gray)
Air vent tube
(translucent)
(3_128_E)
Carriage motor
harness
FG wire
Registration sensor harness
Purge cam sensor harness
Loosen the harness slightly.
(3_006_S13J)
Cable guide
