3-46
Confidential
(2) Remove the two screws (TAPTITE CUP B M3x10) and take off the ADF harness support.
(3) Remove the ADF hinge L from the ADF harness support.
TAPTITE CUP B M3x10
TAPTITE CUP B M3x10
(3_022_E)
ADF harness support
ADF hinge L
