3-55
Confidential
Assembling Note: Assemble new second side CIS flat cable as shown below.
278
150
312
55
7
37
42
93
29
34
15 15
To CIS unit
To main body
UL symbol
print side
Double-sided tape attachment position
To main body To CIS unit
Folding instructions (Unit: mm)
9.5
76 199 150 387
34
Valley fold
Mountain fold
Bottom: UL symbol print side
Top: White side
Insulating tape
(White in color)
Fold
position "A"
*
* : At fold position "A", bend the cable
along the end of the reinforcement plate.
Double-sided tape
Double-sided tape (Bottom when
viewed from this side (White side
and UL symbol print side))
Double-sided tape (Bottom
when viewed from this side
(White side ))
UL symbol
print side
179
182
42
812
120
8
323
45
60
106
30
9.5
45 45 45 45 45 45
(3_CIS_FFC-2_E)
