SPECIFICATIONS
ELECTRICAL SYSTEM
900 ACE
Lightning system output 12V / 650 W
Headlights bulb HI/LOW beam 2 x 60/55 Watts (H-4)
Taillight bulb 2.6 W / 139m W LED
Type MR7B1
Spark Plug
Gap 0.8 mm (.031 in)
F1 : Battery 30 A
F2 : R elay / Start button 5 A
F3 : Starter solenoid 10 A
F4 : Fan 15 A
F5 : HIC 10 A
F6 : HIC / Gauge 10 A
F7 : Front power outlet and
heaters
10 A
F8 : Lighting 20 A
F9 : Unu sed
-
F10 : Rear power outlet 5 A
F11 : Compressor 15 A
R1: Run
R2: Load
R3: Load relay
Fuses and relays
R4: Fan relay
146
