SPECIFICATIONS
ELECTRICAL SYSTEM
1200 4-TEC
Lightning system output 12V/490 W
Headlights bulb HI/LOW beam 2 x 60/55 Watts (H-4)
Taillight bulb LED
Type NGK CR8EKB
(2)
Spark plug
Gap Not adjustable
F 1: Battery 30 A
F 2: Relay/start button 5 A
F 3: Starter solenoid 10 A
F 4: Cooling Fan 15 A
F5: HIC 10A
F 6: HIC/gauge 10 A
F 7: Front power outlet and
heater
10 A
F 8: Lighting 20 A
F 10: Rear power outlet 15 A
Fuses
F 11: Compressor 15 A
R1: Runrelay
R 2: Load relay
R 3: Load relay
Relays
R 4: Cooling fan relay
