Measuring Ampifier Type 2525
User Manual Vol.1
Brüel & Kjær
4–6
Chapter 4 The Menus
Main Set-up
MODEM This option allows you to connect the serial interface to a modem
which can relay the signal through a telephone line to the external
computing device.
Serial Interface Echo menu
This menu allows you to choose whether or not to have the commands sent to and
from the amplifier “echoed” to the send source. That is, if a command is sent to the
amplifier, it is sent back to the sender as soon as the amplifier receives it. In this
way it is possible to monitor that all commands have been properly received. The
options are:
ON
OFF*
4.2.6 Reset Det./Channel
This menu allows you to reset either the detector or the entire analog portion of the
amplifier:
DETECTOR* Only resets the detectors (the data that has been digitized) and
thus does not interrupt the signal on the preamplifier and AC
outputs.
CHANNEL The entire analog portion of the amplifier is reset. This will cause
a disruption in the measurement data received by instruments
further along in the measurement chain (and connected via the
preamplifier output or AC output).
Reset is complete when the selection star on the menu disappears.
4.2.7 SI/Imperical Units
This menu allows you to choose the type of units the ensuing measurement and
display values are to appear in.
SI* Systeme Internationale (metric), according to ISO1000 in metres,
and Newtons
IMPERIAL Inches, lbf, g’s
4.2.8 Decimal Point
This menu allows you to specify the format measurement values will appear in on
the amplifier screen:
