9 Technical Data MS 700‘54
Ascend
9.1 Environmental Conditions
9.2 Identification Plate
The identification plate is on the right rear side attached to the bottom plate of the
cryostat.
Contents of the identification plate:
• Address of the Manufacturer
• Magnet System Identifier
•Type
• Magnet Identifier
• Serial Number
• Year of Construction
• Cryostat Identifier
• Specification Helium Vessel
• Specification Nitrogen Vessel
• Specification Vacuum Chamber
• Weight (empty and completely filled) including magnet stand
Value Unit
Minimum surrounding temperature 7 °C
Maximum surrounding temperature 38 °C
Maximum relative humidity up to 31 °C 80 %
Maximum relative humidity between 31 °C and 40 °C
linearly decreasing
80 – 50 %
Table 9.1: Environmental conditions
