60
ZTKS0164 / Z31949 / 06
Technical Data MS 700‘54 Ascend
9.3 Dimensions
9.3.1 Weights
9.3.2 Dimensions for Transportation
Value Unit
Weight magnet system (empty, without magnet stand) 998 kg
Weight magnet system (completely filled, without magnet stand) 1209 kg
Operational weight (completely filled, with magnet stand) 1370 kg
Weight magnet stand 161 kg
Weight magnet stand (ready for transportation, including box) 250 kg
Weight magnet system (empty, ready for transportation, including
box and transportation locks)
1203 kg
Table 9.2: Weight of the magnet system
L x D x H Unit
Box with magnet system 136 x 114 x 206 cm
3
Box with magnet stand 132 x 74 x 131 cm
3
Table 9.3: Dimensions for transportation of the magnet system
