Technical Data MS 700‘54 Ascend
_ _ _ʹ_ _ _ʹ_ _ _ _
9.17 Magnetic Center
Magnetic Center Value Unit
Distance magnetic center from top flange (MCT) mm
Distance magnetic center from bottom flange (MCB) mm
Shimsystem Offset (SO)
see Figure 9.11: and refer to the supplied Test Protocol AST
mm
Table 9.19: Magnetic center
Figure 9.11: Magnetic center and shimsystem offset (SO)
MC Magnetic Center
MCT Magnetic Center from Top Flange
MCB Magnetic Center from Bottom Flange
SO Shimsystem Offset
This page
wi
ll be
r
ep
l
aced
by specif
i
c
te
c
hnical data.
