SMART MATRIX FEEDER Operation
SMART MATRIX FEEDER 2-3
1 – Navigation inside the Selected Window (STD)
Turn the selector to “Point” in sequence the various items of the window
(STD → WORK TENS.P1 → WORK TENS.P2 → INC/DEC TENS → EDITOR ADVANCED →
EDITOR LOCK).
The frame indicates the “Pointed” field.
Î Î
Î
Click to “Select” the pointed item. The field name will be shown in reverse and the symbols:
appear to the right of the field value.
Example:
WORK TENS.P1 field selected (reverse)
Turn the selector either to Clockwise direction to increase the value, or to Counterclockwise
direction to decrease it (resolution 0.1).
Turn the selector holding the button
pressed to increase/decrease the value more
quickly.
Example:
New value of WORK TENS.P1 = 27.0
Once you have set the desired value (e.g. 27.0), click to confirm.
Example:
WORK TENS.P1 field no more selected
Turn the selector to select a new field and so on ……
To Next Page
