Graphics Display
SMART MATRIX FEEDER 2-44
Set the frequency of synchronism signal
(e.g. 2,000 msec.)
To confirm.
LFA graphic for flat knitting machines (FLAT KNIT application)
This function shows a bar graphic on Smart Matrix Feeder display indicating the amount of yarn consumed in
the two carriage movement directions on flatbed knitting machines (to the left side – L, or to the right side –
R).
Thank to the indication provided by this bar graphic, you will have the possibility to adjust the yarn
consumption in order to make it identical in both directions.
Press the button for direct access to the graphics.
For a correct interpretation of the various graphic
items, please refer to the next page.
To Next Page
