Errors shown on Display of SM-DIN Boards
SMART MATRIX QUILT 2 - 39
Errors shown on Display of SM-DIN Boards
The failures/errors on SM-DIN Boards are indicated by the following codes on the Board’s display:
Generic Alarm.
At least one sensor signaled an alarm.
Error detected during the Learn process.
RAM Error
Error detected on RAM memory contents; the memory will be initialized with the default values.
EEPROM Error
Error detected on EEPROM memory contents; the memory will be initialized with the default values.
Input Signals Error
The Board cannot determine the logical level of the external input signals (EXT).
Communication Error
The Board cannot communicate with one or more sensors.
Programming Error
The Board was not able to program one or more parameters on one or more sensors.
