TS5/TS7 Sensor Features
SMART MATRIX QUILT 3 - 2
TS5/TS7 Sensor Types
The TS5/TS7 sensors are available in various typologies to meet specific needs of individual
installations/applications.
The following diagram shows a detailed coding rule of the available sensors, depending on possible
variables.
Example: TS5/D500DD = TS5 sensor, 500 grams weight, with model D eyelet, Diamond finishing
Eyelet Models
TSX/D
