SLOW-FAST Control Parameters
SMART MATRIX QUILT 3 - 12
Note about the Reset signal
To restart the machine after a stop, it is necessary to release the STOP signal provided either by the SM-DIN
Boards or by the SMART MATRIX Terminal. This operation is performed by the RESET signal which can be
generated either Manually or Automatically (see: Choice of Reset Mode within the SETUP menu). When you
choose the Auto Reset operation, in case of failure detected, the system activates the STOP signal, it
controls the machine status, waiting for the complete stop of the machine it self, then it releases the STOP
signal.
