34. See Figure 3-52. Pull clutch cable back up into the
proper position.
a. Connect clutch cable to handlebars and adjust to
specifications. See 1.9 CLUTCH.
b. Install wire form retainer and tighten fastener to 84-
92 in-lbs (9.5-10.4 Nm).
35. Install sidestand assembly. See 2.40 SIDESTAND.
.
Figure 3-51. Correct Routing of Wiring Harnesses and
Interactive Muffler Cable
11970c
Figure 3-52. Clutch Cable Wire Form Retainer
