Buell 2007 FIREBOLT - Electrical Connectors

B-14 2007 Buell Firebolt: Appendix B
HOME
ELECTRICAL CONNECTORS B.4
GENERAL
The following table provides a brief description of the connec-
tors found on the Firebolt XB9R.
Connector numbers are listed in [brackets] in this manual.
Table B-2. Electrical Connector and Location Table
CONNECTOR COMPONENT(S) DESCRIPTION LOCATION
[5] main fuse spade terminals under seat
[7] tail lamp harness 8-place Multilock left side under tail section
[10] ECM (black) 12-place Deutsch in fairing
[11] ECM (gray) 12-place Deutsch in fairing
[14] cam position sensor 3-place Deutsch under sprocket cover
[18] right rear turn signal 2 1-place bullet under tail section
[19] left rear turn signal 2 1-place bullet under tail section
[22] right hand controls 4-place Multilock beneath right side of fairing
[24] left hand controls 8-place Multilock beneath left side of fairing
[30] flasher 5-place Amp in fairing
[31] right front turn signal 2 1-place bullet beneath right side of fairing
[31] left front turn signal 2 1-place bullet beneath left side of fairing
[33] ignition switch 4-place Augat beneath right side of fairing
[38] headlamp connector 4-place Amp beneath fairing
[39] instrument module 20-place Multilock in fairing
[46] stator 4-place Deutsch under sprocket cover
[61] fuse and diode assembly spade terminals right side of fairing
[62] relay assembly spade terminals left side of fairing
[65] vehicle speed sensor 3-place Deutsch under sprocket cover
[77] voltage regulator 2-place Packard under sprocket cover
[83] ignition coil 3-place Packard beneath air cleaner baseplate
[84] front fuel injector 2-place Packard beneath air cleaner baseplate
[85] rear fuel injector 2-place Packard beneath air cleaner baseplate
[86] fuel pump 4-place Multilock left side of rear shock absorber
[88] throttle position sensor 3-place Packard beneath air cleaner baseplate
[89] intake air temperature sensor 2-place Amp in air cleaner baseplate
[90] engine temperature sensor 1-place bullet beneath air cleaner baseplate
[91A] data link 4-place Deutsch beneath left side fairing
[93] tail light
2-place spade
1-place spade
(ground)
back of tail light
