2007 Buell Firebolt: Appendix B B-15
HOME
[95] clutch switch 2-place Multilock underside of clutch lever assembly
[97] cooling fan 2-place Multilock behind rear cylinder, under seat
[120] oil pressure switch post terminal crankcase above oil filter
[121] front brake switch 2-place Multilock
underside of front master cylinder
assembly
[121] rear brake switch 2-place Multilock under seat
[122] horn 2-spade terminals in fairing
[128] starter solenoid spade terminal top of starter
[131] neutral switch 1-place bullet under sprocket cover
[134] bank angle sensor 6-place Sumitomo in fairing
[137] oxygen sensor 1-place Packard behind rear cylinder head
[161] Interactive exhaust to actuator 4-place Amp under air cleaner cover
[164] Interactive exhaust circuit to ECM spade terminal under seat
[165]
Interactive exhaust subharness to
main harness
3-place Deutsch under seat
[178] Active intake system to solenoid 2-place Deutsch under air cleaner cover
[179] Active intake system to ECM 2-place Deutsch in fairing
Table B-2. Electrical Connector and Location Table
CONNECTOR COMPONENT(S) DESCRIPTION LOCATION
