2007 Buell Firebolt: Starter 5-1
HOME
SPECIFICATIONS 5.1
TORQUE VALUES
Table 5-1. Starter Specifications
STARTER
Free speed 3000 RPM (min.) @ 11.5 V
Free current 90 amp (max.) @ 11.5 V
Stall current 400 amp (max.) @ 2.4 V
Stall Torque 8 ft-lbs (11 Nm) (min.) @ 2.4 V
Table 5-2. Service Wear Specifications
SERVICE
WEAR LIMITS
IN. MM
Brush length (minimum) 0.433 11.0
Commutator diameter
(minimum)
1.141 28.981
ITEM TORQUE NOTES
Battery terminal fasteners 72-96 in-lbs 8-11 Nm page 5-19
Starter battery positive cable
nut
60-85 in-lbs 7-10 Nm page 5-19
Starter mounting bolts 13-20 ft-lbs 18-27 Nm page 5-19
