2-74 2007 Buell Firebolt: Chassis
HOME
FAIRING SUPPORT BRACKET 2.26
REMOVAL
1. Remove seat. See 2.38 SEAT.
11WARNING1WARNING
To prevent accidental vehicle start-up, which could
cause death or serious injury, disconnect negative (-)
battery cable before proceeding. (00048a)
2. Disconnect battery by unthreading fastener removing
negative cable (black) from battery first. See 1.5 BAT-
TERY MAINTENANCE.
3. Remove front fairing. See 2.37 FRONT FAIRING, WIND-
SHIELD, AND MIRRORS.
4. Remove headlight support bracket. See 2.25 HEAD-
LIGHT ASSEMBLY AND SUPPORT BRACKET.
5. Remove fuse block and relay block and p-clamp. See
7.22 MAIN FUSE AND FUSES.
6. Disconnect and remove horn (5). See 7.20 HORN.
7. Disconnect and remove instrument cluster (2, 3). See
7.18 INSTRUMENT MODULE.
8. See Figure 2-105. Remove fairing support bracket fas-
teners and washers (4), p-clamp (7) to remove fairing
support bracket (5).
INSTALLATION
1. Route the wire harness. See D.1 HOSE AND WIRE
ROUTING for wire harness routing.
2. See Figure 2-105. Install fairing support bracket with fas-
teners, p-clamp (7) and washers (4). Tightening to 16-
18 ft-lbs (22-26 Nm).
3. Connect instrument cluster connector and install instru-
ment cluster. Tightening to 12-36 in-lbs (1.3-4 Nm). See
7.18 INSTRUMENT MODULE.
4. Install horn and tighten fasteners to 72-96 in-lbs
(8-10 Nm). See 7.20 HORN.
5. Install fuse block, relay and p-clamp tightening fasteners
to 72-96 in-lbs (8-11 Nm). See 7.22 MAIN FUSE AND
FUSES.
6. Install lower headlight support bracket. See 2.25 HEAD-
LIGHT ASSEMBLY AND SUPPORT BRACKET.
7. Install front fairing. See 2.37 FRONT FAIRING, WIND-
SHIELD, AND MIRRORS.
11WARNING1WARNING
Connect positive (+) battery cable first. If positive (+)
cable should contact ground with negative (-) cable con-
nected, the resulting sparks can cause a battery explo-
sion, which could result in death or serious injury.
(00068a)
8. Install battery by threading positive cable (red) into
threaded hole first tightening to 72-96 in-lbs (8-11 Nm).
See 1.5 BATTERY MAINTENANCE.
11WARNING1WARNING
After installing seat, pull upward on front of seat to be
sure it is in locked position. While riding, a loose seat can
shift causing loss of control, which could result in death
or serious injury. (00070a)
9. Install seat. See 2.38 SEAT.
