3-74 2007 Buell Firebolt: Engine
HOME
INSTALLATION
1. Install oil line fittings with o-ring into swingarm and
tighten to 108-156 in-lbs (12-17.6 Nm).
2. See Figure 3-109. Push the correct flanged oil line into
the correct fitting in the swingarm until each one clicks in
place under the spring clip.
3. Lightly tug on oil line to verify that it is securely locked to
fitting and the spring clip is seated in the oil line fitting
groove.
4. Check oil level and add oil if required.
5. After running engine,
a. Inspect oil fittings for oil leaks.
b. Check oil level and add oil if required.
Figure 3-109. Flanged Oil Line
12021
