2007 Buell Firebolt: Engine 3-77
HOME
Figure 3-111. Oil Cooler Feed Oil Line Orientation (Approximately 2 O’Clock) and Oil LIne Clearances
11971b
10501b
1. Clutch cable
2. 1/8-1/4 in. (3.175-6.35 mm) clearance
3. Feed oil line
4. Return oil line
5. Feed oil line to oil cooler
6. Return oil line from oil cooler
1
2
3
4
3
5
6
