4-72 2007 Buell Firebolt: Fuel System
HOME
Figure 4-51. Ignition Coil Circuit
ISO
ISOISO
KEY SW.
IGNITION
START
87A
Ignition Coil [83]
GN/W
BK/W
R/W
Electronic Control Module
(ECM)
Connector
Connector
Cam Position
Sensor
A
GN/W
Y/BE
GY
BE/O
BK/W
B
C
A
CB
To Rear
Cylinder
To Front
Cylinder
R/W
GY
Ignition Relay
Y/BE
GY
BE/O
Dyno Loop
b1072a4x
[10A]
[83A]
[83B]
[14A]
[14B]
[11A]
[11B][10B]
RELAY CENTER
Table 4-26. Wire Harness Connectors in Figure 4-51.
NO. DESCRIPTION TYPE LOCATION
[10] ECM (black) 12-place Deutsch beneath fairing
[83] ignition coil 3-place Packard beneath air cleaner baseplate
