7-2 2007 Buell Firebolt: Electrical
HOME
TORQUE VALUES
ITEM TORQUE NOTES
Battery (+) to starter fastener 60-85
in-lbs
7-10 Nm page 7-33
Battery ground cable and
actuator ground wire
48-72
in-lbs
5.4- 8.1 Nm page 7-69
Battery terminal fasteners 72-96
in-lbs
8-10.8 Nm page 7-34, 7-40, 7-66
clutch switch fasteners 7-10
in-lbs
0.8-1.12 Nm page 7-15
Exhaust actuator 36-40
in-lbs
4.1-4.5 Nm page 7-21
Fork clamp, upper 20-22 ft-lbs 27-29.8 Nm LOCTITE 271 (red), page 7-8
Fuse block mounting fasteners 72-96
in-lbs
8.1-10.8 Nm page 7-65
Handlebar control housing
screws (left side)
25-33
in-lbs
3-4 Nm page 7-50
Handlebar control housing
screws (right side)
25-33
in-lbs
3-4 Nm longer screw on bottom, page 7-50
Horn fastener 72-96
in-lbs
8.1-10.8 Nm page 7-59
Ignition switch body fastener 12-36
in-lbs
1.4-4.0 Nm page 7-7
Ignition switch fasteners 18-20 ft-lbs (24.4-27.1 Nm) LOCTITE 271 (red), page 7-8
Instrument module fastener 12-36
in-lbs
1.4-4.0Nm page 7-53
Main battery ground to frame 48-72
in-lbs
5.4-8.1 Nm page 7-33
Neutral indicator switch 60-84
in-lbs
6.7-9.5 Nm LOCTITE 243 (blue), page 7-61
Relay block mounting fasten-
ers
72-96
in-lbs
8.1-10.8 Nm /Always install with new fasteners, page 7-65
Rotor mounting fasteners 120-140
in-lbs
13.5-15.8 Nm
LOCTITE THREADLOCKER 243 (blue), page 7-
31
Spark plugs 12-18 ft-lbs 16-24 Nm page 7-1
Stator TORX mounting screws 30-40
in-lbs
3-4 Nm
T-27 TORX with retaining compound, replace with
new after each removal, page 7-31
Steering head wiring clamp 16-18 ft-lbs 21.7-24.4 Nm page 7-65
Steering stem cap 38-42 ft-lbs 52-57 Nm LOCTITE 271 (red), page 7-8
Steering stem pinch fastener 23-25 ft-lbs 31-34 Nm LOCTITE 271 (red), page 7-8
Tail light lens and tail light 6-7
in-lbs
0.7-0.8 Nm page 7-44
Turn signal fastener (rear) 25-28
in-lbs
2.8-3.2 Nm page 7-47
Turn signal fasteners (front) 25-28
in-lbs
2.8-3.2 Nm page 7-47
Turn signal flasher fastener 36-60
in-lbs
4-6.7 Nm page 7-48
Voltage regulator mounting
fasteners
36-60
in-lbs
6.7-8 Nm page 7-32
