Throw sifter Transport 17
© Copyright 2018 Bühler AG DFTA-66620-2-en-1803
3 Transport
Allow personnel to transport the system only if they are familiar with the task and
have received proper training.
3.1 Crane suspension
The machine is shipped completely assembled and ready for connection. For trans-
port, the sieve box is fastened in place by four transport stabilisation devices (1) and
(2) that are attached to the sides. These devices are marked with yellow paint and
must be removed before commissioning the machine.
Danger!
Never walk beneath suspended loads.
Caution!
Check to ensure that the crane and lifting gear are designed such that they can
bear the load, and verify their maximum permitted load.
Hoist the machine at the specified suspension points only.
(Refer to Fig. 3.3,
18)
Fig. 3.1
(1) Upper transport stabilisation device (2) Lower transport stabilisation device
