Buhler DFTA 12 - Sieve Clamping

36 Maintenance Throw sifter
DFTA-66620-2-en-1803 © Copyright 2018 Bühler AG
7.4 Sieve clamping
Fig. 7.2
45 1011
2
8
13, 14
1
3
8
1
2
8
1
6
7
9
12
6
7
6
7
Sieve loose
Sieve clamped
(1) Sieve frame
(2) Clamping bar
(3) Centre clamping bar
(4) Straight pin
(5) Upper eccentric bushing
(6) Lower eccentric bushing
(7) Spacer bush
(8) Spacer bush
(9) Attachment stay
(10) Bearing bush
(11) Set collar
(12) Hexagon bolt
(13) Seal
(14) Guard plate
