Technical data
Type 8202/8222
6.3.3. Electrical data
Power supply
Version with 3 outputs
Version with 4 outputs
14-36 V DC, filtered and regulated
12-36 V DC, filtered and regulated
Characteristics of the
power source (not sup-
plied) of the UL versions
limited energy source (in
accordance to UL 61010-1,
paragraph 9.3)
or Class 2 source (in accordance
to standards 1310/1585 and
60950-1)
Current consumption
Version with 3 outputs
Version with 4 outputs
25 mA max. (at 14 V DC)
5 mA max. (at 12 V DC)
Current consumption, with
loads on the transistors
1 A max.
Power consumption 40 W max.
Protection against polarity
reversal
yes
Protection against voltage
spikes
yes
Protection against short
circuits
yes, transistor outputs
Transistor output NPN (/sink) or PNP (/source)
(depending on software setting),
open collector, 700 mA max., 0.5 A
max. per transistor if both transistor
outputs are wired.
NPN output: 0.2-36 V DC
PNP output: supply voltage
Current output
Response time (10 % -
90 %)
Version with 1 current
output
Version with 2 current
outputs
4-20 mA, sink ("NPN sink") or source
("PNP source") (depending on
software setting)
150 ms (default value)
max. loop impedance: 1100 W
at 36 V DC, 610 W at 24 V DC,
180 W at 14 V DC
max. loop impedance: 1100 W
at 36 V DC, 610 W at 24 V DC,
100 W at 12 V DC
