22
Installation
Type 8202/8222
B
→ Check the presence and the condition of
seal B on the fitting. Replace the seal if
necessary.
→ Insert the holder with its probe carefully
into the fitting.
→ Tighten the nut on the fitting by hand.
→ Charge the pipe to check that the
mounting is tight.
Fig. 14: Installing the sensor holder with its probe on a fitting
(8202)
→ If the sensor holder is tight, insert the electronic module back
onto the sensor holder as shown in Fig. 15.
electrical contacts
→ Check that the electrical
contacts are in good
condition and clean them
with a brush if necessary.
A
polarising slots
→ Check that seal "A" on
the holder is in good
condition. Replace it if
necessary.
→ Insert the electronic
module into the holder,
making sure the
polarising slots are
correctly positioned.
English
