YAK 130
BVM ©2016 35 Mar. 23, 2016
Wing Prep and Installation
Flap Install
Match up the Wing with the correct Flap.
The large control horn is the inside hinge
and control horn. The small horn is a
hinge only.
Remove the (2) 2mm SHCS and (2) 5mm
lock nuts from the wing side of the Flap
hinge.
Use a small awl to line up the horns.
