YAK 130
BVM ©2016 51 Mar. 23, 2016
Center of Gravity
The C/G is 6” aft of the leading edge fairing on
the fuselage as shown.
The C/G is also located by the factory with ink
on the side of the wing fairing.
Drill a 1/16” hole on the bottom side of the
wing root fairng at the 6” point.
Install a #2 button head screw for ease of
locating when model is fully assembled.
Repeat this process for the other side.
Balancing the Model
1. Referencing the button head screws.
2. Balance the model fully assembled.
3. Empty fuel tanks
4. Gear in the down position
5. Full U.A.T.
6. With a correct Center of Gravity, the model should balance close to level. Nose or Tail
could tip down.
