Replacing the Burner
Release tabs
1. Remove the mixing chamber by gently pulling back
on the 2 release tabs and pulling the mixing chamber
in a downwards direction.
2. Remove the 2 thumb screws holding the burner
flange into position, whilst securely holding the
burner (failure to hold the burner will cause it to
drop out when the screws are removed).
3. Carefully lower the burner from the housing.
4. Replace the burner.
5. Reassemble in reverse order.
